Khoom Description
Lub 5 axis cnc cuab yeej sib tsoo tshuab sib tsoo spindle txais kev siab -precision, synchronous, ncaj-tsav zaus hloov hluav taws xob ntxaiv, nruab nrog ob lub sib tsoo lub log flanges muaj peev xwm mounting 2 mus rau 4 lub log sib tsoo. Qhov no tso cai rau kev hloov ceev ntawm lub log raws li kev sib tsoo sib txawv, ua tau raws li kev xav tau ntawm ntau yam cuab yeej geometry. Lub A-axis (workpiece spindle) nta ncaj qha-tsav servo thev naus laus zis, SCHAUBLIN siab-txoj hlua khi, thiab pneumatic tsis siv neeg clamping, muab kev ua haujlwm zoo thiab ruaj ntseg.
Lub TG560 5 axis cnc cuab yeej sib tsoo tshuab yog nruab nrog SYNTEC 210MA-5E 5-axis CNC tswj qhov system thiab servo chav tsev, kev koom ua ke nrog cov kev sojntsuam siab, PMI precision pob screws, thiab cov kab qhia qhia kom lav qhov kev sib tsoo zoo dua thiab kev ua haujlwm tag nrho. Lub tshuab boasts ib tug tag nrho enclosed tsim, nrog rau pem hauv ntej zawv zawg qhov rooj thiab rear/sab txij nkawm qhov rooj, thiab los ntawm tus txheej txheem nrog ib tug electronic handwheel, pib / nres tswj khawm, ko taw pedal, tsis siv neeg coolant system nrog filtration tank, tsis siv neeg lubrication system, suction interface, tswb buzzer, thiab hluav taws xob txee cua txias-xyuas ob qho tib si kev yooj yim ntawm kev khiav hauj lwm.
Nrog rau nws cov kev teeb tsa siab heev thiab kev ua tau zoo, TG 560 yog qhov kev daws teeb meem zoo tshaj plaws rau cov tuam txhab tsim cov cuab yeej, cov cuab yeej sib txuas cov chaw muab kev pabcuam, thiab siab -kawg machining chaw nrhiav kev txhim khu kev qha thiab cov cuab yeej sib tsoo muaj peev xwm.
Cov cuab yeej txheem ntawm 5-Axis CNC Tool Sib Tsoo Tshuab
5 axis cnc cuab yeej sib tsoo tshuab lub cev
CNC SYNTEC 210MA-5E CNC system thiab servo chav tsev
Kev sojntsuam
11KW precision direct tsav sib tsoo taub hau
HSK ceev hloov precision flange pas nrig
W25 workpiece tsis siv neeg clamping ntaus ntawv
Mist suction interface
Tsis siv neeg lubrication ntaus ntawv
Tsis siv neeg cua txias tswj ntaus ntawv
Xaiv qhov chaw thiab cov khoom siv yeem
SCHUNK kov
SHAUBLIN W20 cuab yeej tuav thiab collet
Tshwj xeeb fixture
Sib tsoo log
Tsis siv neeg pub khoom noj
RENISHAW LP2DD sojntsuam
ITALIAN Marposs sojntsuam, thiab lwm yam.
Roj av Separator
Lub zog muaj zog & ruaj khov ua haujlwm
1. yeem
Tsis siv neeg loading & unloading ntaus ntawv
2. Ultra-Precision Ntsia Hlau
Txais yuav imported siab -precision pob ntsia hlau, ua haujlwm du thiab lub neej ntev.
3. High precision qhia
Nrog siab - lub zog taw qhia qhov tseeb thiab kev ua haujlwm du.
4. Intelligent vaj huam sib luag
Tus kheej- muaj vaj huam sib luag, yooj yim rau kev khiav lag luam thiab txhim kho kev ua haujlwm.
Ultra{0}} qhov tseeb ntsia hlau
Txais yuav imported siab - precision pob ntsia hlau, ua haujlwm du thiab lub neej ntev.
High precision qhia
Nrog siab - lub zog taw qhia qhov tseeb thiab kev ua haujlwm du.
Marble txaj
Txhim kho kev poob siab tsis kam thiab ruaj khov.
Cim npe nrov: Tuam Tshoj 5 axis cnc cuab tam sib tsoo tshuab manufacturers, lwm tus neeg, Hoobkas
Technical parameter
|
Qauv |
TSI 560 |
|
CNC system |
SYNTEC 210MA-5E |
|
Max. Ua haujlwm workpiece txoj kab uas hla (Dis hom) |
200 hli |
|
Max. Ua workpiece txoj kab uas hla (Bar hom) |
3-12 hli |
|
Max. ua haujlwm workpiece ntev |
270 hli |
|
Max. ua workpiece groove qhov tob |
10 hli |
|
Max. Workpiece hnyav |
10 KG |
|
Sib tsoo taub hau Max. Lub zog (lub zog spindle) |
11KW/22KW TSI |
|
Sib tsoo log (CBN / pob zeb diamond) |
Φ50-Φ200mm |
|
Sib tsoo taub hau spindle rotation speed (frequency regulation) |
1000-6000 rpm |
|
Vertical lifting stroke ntawm workpiece taub hau ncej (Z axis) |
360(-100/{2}}) hli |
|
Ua haujlwm tau mus ncig X axis/Y-axis |
X: 450mm / Y: 590mm |
|
Linear axis ceev mus ncig ceev |
15m / min |
|
Workpiece spindle kev sib hloov ceev (A-axis) |
200 rpm |
|
Kev sib hloov ntawm A-axis |
∞ |
|
clamping ntau |
Φ3-Φ20mm |
|
Tsis siv neeg clamping workpiece ntau yam |
Φ3-Φ20mm |
|
Sib tsoo taub hau viav vias Max kev sib hloov ceev (C-axis) |
30rpm ua |
|
Kev sib hloov ntawm C-axis |
325℃(+230℃~ -95 degree) |
|
Workpiece spindle center qhov siab |
150 hli |
|
Workpiece spindle radial runout |
Tsawg dua los yog sib npaug li 0.005mm |
|
Sib tsoo taub hau spindle radial runout |
Tsawg dua los yog sib npaug li 0.005mm |
|
Cua lub tog raj kheej clamping quab yuam kho ntau yam |
700-800 kg |
|
Linear{0}}axis daws lub zog |
0.001 hli |
|
Kev sib hloov axis daws lub zog |
0.001 degree |
|
Qhov hluav taws xob |
AC 380V 50HZ 3 theem |
|
Tag nrho lub zog |
20KW / 32KW TSI |
|
Tshuab qhov ntev (tsis muaj manipulator) |
1700 × 1730 × 2100 hli |
|
Tshuab qhov ntev (nrog manipulator) |
2550x1750x2100mm |
|
Tshuab hnyav |
4T |
